Thermostat Controller

Thermostat Controller

Part Number: TC306

ITC-306T is a pre-wired heating output temperature controller

This plug and play product is designed with dual LCD display, and offers the optional display of Centigrade or Fahrenheit, which makes it more humanized temperature control.

With large power output 1,200W, it’s suitable for most applications.

The temperature can be controlled more accurately with its function of temperature calibration and temperature hysteresis.

  • Plug and play design, easy to use;
  • Dual time cycle setting during 24hours, can be set different temperature from day and night on the basis of the physical needs of animals and plants;
  • Support reading with Centigrade or Fahrenheit unit;
  • Maximum output load: 1200W(110V) / 2200W(220V);
  • Dual display window, be able to display measured temperature and set temperature at the same time;
  • Temperature calibration;
  • Over-temperature and sensor fault alarm
  • Temperature Control Mode :On/Off Control, Heating
  • Temperature Control Range : -50~99 °C / -58~210 ° F
  • Temperature Resolution: 0.1 ° C / 0.1° F
  • Temperature Accuracy: ±1°C (-50 ~ 70°C) / ±1°F (-50 ~ 160° F)
  • Input Power: 100 ~240VAC, 50Hz/60Hz
  • Temperature Control Output: Max. 10A, 100V ~240V AC
  • Relay Contact Capacity: Heating (10A, 100-240VAC)
  • Input Power Cable Length: 1.5m (5ft)
  • Output Power Cable Length: 30cm (1ft)



This unit can be used for more than controlling our plating kits temperature.



This unit will replace the HTS15 which has been our standard thermostat for the last 15 years.













Price: $49.95
