CHRPK4G Hard Chrome Plating Kit Large

Hard Chrome Plating Kit Large

Part Number: CHRPK4G

Hard Chrome is used to rebuild shafts, bearing and sometimes used to plate golf club heads and firearms.

Chrome plating can be used for two purposes:
  1. Hard Chrome Plate
    • Usually used to build up shafts or areas on steel that are subject to severe wear. The hard chrome plating process can take several hours to build up. The procedure is discussed extensively in The Complete Plating Manual, paying particular attention to the hard tipping of cutting tools.
  2. Decorative Chrome Plate
    • Most chrome plate is considered 'decorative'. It is a very thin layer, approx. 1/100th the thickness of a human hair, which is applied over a NICKEL plate. Chrome offers NO corrosion resistance, as it is porous, so the nickel does all the protection. The chrome merely gives the nickel a 'blue' look, and stops it tarnishing. Decorative chrome plate can be considered a 'clear coat' over the nickel 'paint job'. This chrome plating kit is NOT capable of decorative chrome plating. If you are interested in decorative chroming, you'll likely want to purchase our Triple Chrome Plating Kit.

Hard Chrome Plating is often used in industry to build up areas that are subject to wear, pistons, firearms and golf club heads. The anodes are shaped, or "conformed" to the part being plated, to assure an even plate.

Hard Chrome plating requires large amounts of DC current (approx 2 amps per square inch). This makes the larger operations more impractical for the smaller workshop.

You can chrome plate with a 6 or 12 volt battery, or charger, but if larger parts are involved, you may need to use 2 batteries. The higher amperage required can also be controlled by the inexpensive construction of a 'salt water rheostat', a device made from a plastic tank, some salty water and 2 metal plates.


Acid mist is produced during the chrome plating process from the vigorous action of the higher current used. This mist could be compared to dropping several 'Alka Seltzers' into water, and needs to be controlled by either making a small fume hood, (a cooking stove hood is ideal) or wearing a respirator fitted with 'Acid Gas' cartridges. Fume Control Balls and chemical mist suppressant are supplied with the kit to reduce this problem.

The Chrome Crystals supplied with the kit contain sufficient chrome to plate over 1000 square feet of chrome plate per gallon of made up solution. You should never need to replace this material. The Chrome is removed from the Chromic Acid solution, and the anodes are not sacrified. It is unnecessary to replace these anodes.

This kit runs at room temperature, between 18 deg C and 32 deg C. a heater is not supplied in Australian kits.

The Large Kit Contains:

  • 1 x 15 litre Plating Tank and lid
  • 4 x Can Chrome Crystals
  • 2 x 300mm x 150mm Chrome Anode
  • Mist Control Balls
  • Mist Suppressant
  • The Complete Plating Manual
  • Free Technical Support

Makes c. 10.8 Litres of working solution





Contains Hazardous Goods. Shipping restrictions apply




YOU MUST SUPPLY

Power Supply


Copper Pipe for tank bar
Copper Wire to hang items
Small amount of electrical wire to make connections
Distilled water


Price: $589.00

HAZMAT Item:

 This Item is a HAZMAT item.
We cannot ship this overseas or to some very remote locations in Australia.
We cannot ship this item to a PO Box or parcel locker it must be delivered to a residential or business address.

Because it is a Hazardous item, couriers cannot guarantee delivery times as they have to manage compatibility of all materials they carry. This does not generally affect the delivery of aerosols.
